Supreme Model S3000 Crash Barrier
Customized High-Performance Stainless Steel Crash Barrier
Functional Parameters
- Reflective Tape: Imported 3M.
- Warning Light: LED Beads
- Buffer Pad: 4
- Impact Resistance: Normal operation after impact with 12-ton load
- Damage Resistance: Bollard deforms after impact with 16-ton load
- Assembly Structure: Integrated Installation
- Drainage Method: Seepage or drainage system
- Positioning Method: Fixed-point positioning, NVH (Noise, Vibration, and Harshness)
- Support Protective Rod: Diameter M16
- Guidance Protective Sleeve: 4
- Double-layer Anti-collision Beam: 12mm
Product Technical Parameters
- Column Diameter: 219mm
- Column Material: High-quality Stainless Steel
- Column Wall Thickness: 6~20mm (Customizable)
- Panel Material: High-quality Stainless Steel
- Panel Size: Diameter 420mm
- Sleeve Material: High-quality Stainless Steel
- Sleeve Size: Diameter 325mm, Height 1145mm
- Operating Structure: Four-column concentric guidance
- Guide Column Diameter: 20mm
- Column Surface Treatment: Polished Outer Circle
- Column Lifting Height: 600mm
Product Technical Parameters
- Stroke Height: 1048mm
- Power: 550/760W
- Rated Current: 1-10A
- Power Connection: 5 * 2.5
- Installation Method: Vertical
- Lifting Time: 1-2 seconds
- Lowering Time: 2-3 seconds
- Oil Pump: Imported Oil Pump
- Power Supply: 220V
- Thermal Protection: Automatic Sensing
- Oil Tank Capacity: 4L
- Protection Level: IP68
- Emergency Pressure Relief Voltage: DC12V
- Maximum Load: 300KG
- System Pressure: 8MPA
- Synchronization Standard: ±0.05s
- Operating Temperature: -25°C-70°C
- Usage Frequency: Intermittent Use
Hebei Qixinlong Smart S3000 Bollard System
Intelligent Lifting & Stable Protection | Full - Scenario Smart Bollard Solution
Smart Anti - collision Column for Exhibitions
Exhibition Public Areas: Intelligent Rapid Response + High-Strength Protection for Personnel & Asset Safety.
Intelligent Indoor Anti - collision Column
Indoor Spaces (Malls/Offices): Smart Lifting for Clear Access & Impact-Safe Security.
S3000 Supreme All - Scene Anti - collision Column
Multi-Scene Use (Roads/Parks/Venues): Smart Linkage + Military-Grade Durability. Qixinlong's Flagship Solution.
Supreme Model S3000
The stainless steel column is processed and formed through a series of operations including grinding, deburring, rough polishing, and fine turning.
Product updates are subject to the actual product
The column cover plate has compressive capacity to withstand loads after the bollard descends; the column top cover is turned with a knurled texture for decorative design.
Adopts DC12V warning lights with high brightness and good light transmittance; ensures the light strip maintains normal operation after submersion in water or impact.
The reflective film uses microprism technology, with a reflective brightness more than 4 times that of engineering-grade films and more than 2 times that of traditional high-intensity films. Its unique reflective principle also gives it ultra-wide reflective angles.
The body is made of stainless steel, and the outer surface of the sleeve is polished.
Pressure-driven, capable of normal operation when submerged in water, high protection against liquid and solid particles, high-precision sealing to prevent dust ingress.
The bottom of the cast-in sleeve is equipped with a weep hole to prevent long-term water accumulation, thereby improving operational performance and extending service life.
